2010-2019 BMW S1000RR/R/HP4/XR STAGE 2 (Final Edition Map Upgrade)

**"Final Edition" (Stage 2) mapping upgrade is only for customer that already have the BT Moto handheld with our Stage 1 mapping**

2010-2019 STAGE 2 / FINAL EDITION

Since our release of Stage 2 we have found a few other restrictions and improvements in the 2010-2019 BMW S1000RR ECU. The long awaited cooling fan mod is now available on all BMSK/BMSX/BMSM-P BMW bikes 2010-2019 BMW S1000RR/HP4. We have also incorporated new features and we have found even more functions and small bits of power with this update. This converts it to a newer S1000RR model power levels and mid-range.

WHAT'S INCLUDED WITH THE "FINAL EDITION"?​​

• Maximum speed on the quick shifter
• Recalculation of the ASC torque control for straight line and cornering for maximum performance
• Per-cylinder fuel tuning done with 4 channel wideband
• Aggressive fuel and max power ignition targets
• Remapped throttle angles for increased power across the entire RPM range. 100% throttle soon as possible for best torque
• Porting of race ECU additions from WSBK spec ECUs for TCS, ASC, wheelie control
• Higher trap speeds and top speeds in real world testing especially on VP fuels
• Meant for premium fuels 93+ (98 RON)
• MAX cooling and engine IAT compensation prevention in staging lanes idling for drag strip or circuit standing starts

***FINAL EDITION IS FOR FULLY MAXIMIZED MOTORCYCLES LOOKING TO GET THE MOST FROM THEIR MOTORCYCLE USING HIGH OCTANE FUELS***

STAGE 2 DYNO RESULTS

Stage 1 vs Stage 2 pictured below. Average gains of +6-8TQ and +5-6HP With More Mid Range power Than Stage 1 ECU Flash

​

DYNO TESTING (2015-2016 S1000RR)

STOCK TUNING VS STAGE 2

RED (Stock Baseline. 93 pump gas) = 172whp

BLUE (Stage 2, 93 pump gas) = 194whp

2016 S1000RR with built engine and Stage 2 vs Rapid Piggyback with built engine (BELOW)

DYNO TESTING (2010-2014 S1000RR)

The 10-14 S1000RR's make very noticeable power gains with the Final Edition mapping

BLUE (Stock mapping 91 pump gas) = 187whp

RED (Stage 2/Final Edition, 91 pump gas) = 197whp

GREEN (Stage 2/Final Edition, MR12 race fuel) = 209whp

***DISCLAIMER: FOR CLOSED COURSE COMPETITION USE ONLY. NOT INTENDED FOR STREET USE***
