FOX Track shocks: Float 3 QS3 LW/EVOL QSL-QSR LW RMK KHAOS Matryx

Adjustments:

FLOAT air spring

EVOL air chamber

QS3 ? 3 position compression (front track), with lockout mode (rear track)

QSR ? 3 position rebound

Features:

Optimized lightweight shock design

Spiral groove bypass

One-piece, aluminum spherical bearings

High-flow velocity-sensitive damping

Fully re-buildable and re-valvable

Front Track Extended Length: 11.950

Front Track Compressed Length: 8.490

Front Track Travel: 3.460

Rear Track Extended Length: 17.130

Rear Track Compressed Length:10.940

Rear Track Travel:5.570

Air Spring Pressures:

Front Track Main - 25psi

Rear Track Main - 140psi

EVOL - 145psi

Top Mount: Eyelet

Bottom Mount: Eyelet

Rebuild P/n: FT 803-01-572; RT 803-01-574

Reservoir: Piggyback

Front Track Extended Length: 11.9500

Front Track Compressed Length: 8.4900

Front Track Travel: 5.5700

Rear Track Extended Length: 11.9500

Rear Track Compressed Length: 10.9400

Rear Track Travel: 5.5700

Fitment notes:

Track (Front & Rear)
